DomeGallery

What Does It Do? (Plain English)

A grid of image tiles arranged on the surface of an invisible sphere. Drag to spin the sphere; let go and it coasts to a stop with a touch of inertia, the way a globe on a desk does. Tap any tile and it flies out from where it sat to a centred lightbox, ready to read. Tap outside or press Escape and it flies back home.

Think of it as a snow globe full of photographs — except instead of glass, the dome is built entirely from CSS 3D transforms (rotateX, rotateY, translateZ, perspective). There is no Three.js, no WebGL, and no canvas: every tile is a real <img> inside a regular DOM element, so they remain selectable, focusable, and indexable.

How It Works (Pseudo-Code)

state:
  rotation   = { x: 0, y: 0 }   // reactive — drives sphere transform
  dragging   = false
  moved      = false            // exceeded click vs drag threshold?
  velocity   = { x: 0, y: 0 }   // updated every pointermove
  enlarging  = false            // reactive — drives lightbox class
  inertiaRAF = null             // active requestAnimationFrame id

derive:
  items = buildItems(images, segments)   // grid coords + photo data per tile

events:
  on ResizeObserver:
    radius = clamp(min, basis × fit, max); write --radius CSS var

  on pointerdown over sphere:
    if focused (lightbox open): ignore
    stopInertia(); dragging = true; moved = false
    capture pointer; lockScroll(); snapshot startRot/startPos

  on pointermove (skip if !dragging):
    update velocity (Δposition / Δtime)
    if drag distance² > 16 px² → moved = true
    rotation.x = clamp(start − dy/sensitivity, ±maxVerticalRotationDeg)
    rotation.y = wrap(start + dx/sensitivity)
    apply transform on sphere element

  on pointerup:
    if |velocity| significant: startInertia(vx, vy)
    if !moved AND target was a tile: openItemFromElement(tile)
    release pointer; unlockScroll()

  on tile open:
    capture tile rect; FLIP-style transform from tile → centre
    enlarging = true; lockScroll()

  on Escape / scrim click:
    FLIP back to original tile rect; remove overlay; unlockScroll()

inertia step (rAF):
  vX *= friction; vY *= friction
  apply rotation; recurse until |v| < threshold OR frames > maxFrames

The Core Concept: Building a Sphere From Flat Tiles

The "sphere" is a stack of plain rectangles, each rotated to the right latitude/longitude and pushed outward by radius so its centre lands on the imaginary spherical surface.

.stage          { perspective: 1200px; }            // viewer eye
  └── .sphere   { transform: translateZ(-radius)
                            rotateX(rotation.x)
                            rotateY(rotation.y); }
        ├── .item   transform: rotateY(longitude)
        │                       rotateX(latitude)
        │                       translateZ(radius);
        ├── .item   …
        └── .item   …

For each tile at grid position (offsetX, offsetY) with segments columns:

unit     = 360° / segments / 2     // half-step per grid unit
rotateY  = unit × (offsetX + (sizeX − 1) / 2)    // longitude
rotateX  = unit × (offsetY − (sizeY − 1) / 2)    // latitude

Why halve the step? The brick-stagger pattern increments grid X by 2 between columns and uses two interleaved Y arrays (evenYs = [-4,-2,0,2,4], oddYs = [-3,-1,1,3,5]), which means consecutive visual columns are only one half-step apart. Halving the unit puts them on a continuous angular grid without overlaps.

translateZ(radius) is the trick that turns a 2D layout into a sphere surface: each tile, after its rotations, points outward from the origin and is then pushed exactly radius units along its own local Z axis. The sphere itself is then translated -radius on Z so the near face of the dome sits at the viewer's eye position — that's why a tile at rotation (0, 0) appears flat against the screen.

A staggered brick pattern (rather than a regular grid) is used so the tile seams do not line up into obvious horizontal/vertical bands when the dome rotates — the eye reads a brick pattern as "varied" and a uniform grid as "rigid".

Performance: Where the Frame Budget Goes

The component holds a strict invariant: only rotation and enlarging are reactive Svelte state. Everything else (dragging, velocity, lastMovePos, RAF ids) is plain JS that mutates without triggering re-renders. When rotation changes, the sphere's transform is rewritten directly via DOM API, not via re-rendering children.

Per drag-frame: two clamp/wrap calls and one applyTransform (one CSS transform string written on the sphere element). Per inertia frame: identical, plus one requestAnimationFrame schedule. The friction loop terminates on two conditions (velocity below threshold OR frame count over a maximum) so a stuck animation cannot run forever.

Three CSS rules earn their keep:

.sphere { will-change: transform; }
.item   { backface-visibility: hidden; }   /* skip rear-facing tiles */
.stage  { contain: layout paint size; }    /* isolate from page layout */

backface-visibility: hidden is the big one — half the tiles face away at any moment, and culling them at the GPU level halves the per-frame fill cost. contain: layout paint size means the rest of the page never has to lay out or repaint when the dome rotates.

Image tags use the browser's standard lazy-decode path. Add loading="lazy" and decoding="async" on tiles that will start off-screen if you have many — the component itself does no lazy-loading, keeping it portable.

Accessibility Deep-Dive

• Each tile is a real focusable element with role="button", tabindex="0", and an aria-label derived from its alt text — Tab walks the tile set in DOM order regardless of where they sit visually.
• Enter / Space opens the lightbox; Escape closes it; focus is restored to the originating tile.
• The lightbox locks page scroll (document.body gets the dg-scroll-lock class). The lock is released only when both enlarging is false AND dragging is false — the two states share one lock so neither can leak.
• For prefers-reduced-motion: reduce, set dragDampening={0} to suppress inertia coast and enlargeTransitionMs={0} for instant lightbox swaps.
• The 16 px² click-vs-drag threshold matters for keyboard users too: Enter/Space never accidentally triggers drag logic, and mouse users with shaky hands get a small grace zone.

State Flow Diagram

              ┌────────────────────┐
              │       IDLE         │
              │  rotation = {0,0}  │
              │  enlarging = false │
              └─────────┬──────────┘
                        │ pointerdown on sphere
                        ▼
              ┌────────────────────┐
              │      DRAGGING      │
              │  rotation updates  │
              │  velocity tracked  │
              │  scroll locked     │
              └─────────┬──────────┘
                        │ pointerup
            ┌───────────┴────────────┐
            │                        │
   moved & |v| significant       !moved & on tile
            │                        │
            ▼                        ▼
   ┌────────────────┐      ┌──────────────────┐
   │   COASTING     │      │    ENLARGING     │
   │  rAF friction  │      │  FLIP tile→centre│
   └────────┬───────┘      └─────────┬────────┘
            │ |v| < threshold         │ Escape / scrim
            ▼                         ▼
           IDLE                   FLIP back → IDLE

Props Reference

Prop	Type	Default	Description
images	(string | DomeGalleryImage)[]	[]	Array of { src, alt } objects or plain URL strings. Cycles to fill all grid slots.
fit	number	0.5	Multiplier applied to the chosen container basis to derive the sphere radius.
fitBasis	'auto' | 'min' | 'max' | 'width' | 'height'	'auto'	Which container dimension drives the radius calculation.
minRadius	number	600	Lower bound on the sphere radius in pixels.
maxRadius	number	Infinity	Upper bound on the sphere radius in pixels.
padFactor	number	0.25	Padding applied around the viewer as a fraction of the basis dimension.
overlayBlurColor	string	'#060010'	Colour used by the radial vignette that fades the dome edges.
maxVerticalRotationDeg	number	5	Hard clamp on vertical (X-axis) rotation, in degrees.
dragSensitivity	number	20	Pixels of pointer movement per degree of rotation; lower = more sensitive.
enlargeTransitionMs	number	300	Duration of the FLIP open/close animation.
segments	number	35	Number of grid columns; more = smaller, denser tiles.
dragDampening	number	0.8	0–1 inertia tuning: 0 = no coast, 1 = long coast.
openedImageWidth	string	'250px'	Width of the enlarged image.
openedImageHeight	string	'350px'	Height of the enlarged image.
imageBorderRadius	string	'30px'	Border radius applied to grid tiles.
openedImageBorderRadius	string	'30px'	Border radius applied to the enlarged image.
grayscale	boolean	true	Apply a grayscale(1) filter to the tiles for an editorial look.

Edge Cases

Situation	Behaviour
Small viewport (mobile portrait)	ResizeObserver recalculates --radius against the smaller dimension; the dome shrinks proportionally and tiles remain readable. touch-action: none ensures vertical page scroll is not stolen by horizontal drags.
Image fails to load	The browser's broken-image glyph appears in that tile; nothing else changes. Surrounding tiles continue to render and the dome remains interactive.
Slow network	Tiles render their backing <img> immediately; pixels stream in as the network delivers them. Pre-decode by adding decoding="async" and loading="lazy" to image sources.
prefers-reduced-motion: reduce	Pass dragDampening={0} to suppress inertia coast and enlargeTransitionMs={0} for instant lightbox swaps. The dome remains static unless dragged.
Keyboard-only user	Tab walks tiles in DOM order; Enter/Space opens, Escape closes and restores focus to the originating tile.
Click landed mid-coast	Pointer-down calls stopInertia() first, so a coasting dome can be caught and re-grabbed without delay.
More / fewer images than tiles	More: console.warn and excess ignored. Fewer: array cycles; a swap-pass guarantees no two adjacent slots repeat.
Dark mode page	Theme-agnostic — set overlayBlurColor to the page background to make the edge fade blend. Default #060010 suits dark themes.
Component unmount mid-drag	$effect cleanup cancels inertiaRAF and removes the scroll-lock class so unmounting cannot strand the page locked.

Dependencies

• Svelte 5.x — $state, $derived, $effect, and $props. Reactive state is deliberately limited to rotation and enlarging; everything else is plain JS for performance.
• Zero external dependencies — no Three.js, no canvas, no animation library, no icon library. CSS 3D transforms, ResizeObserver, and the Pointer Events API are the only browser features used.

File Structure

src/lib/components/DomeGallery.svelte         # implementation
src/lib/components/DomeGallery.md             # this file (rendered inside ComponentPageShell)
src/lib/components/DomeGallery.test.ts        # vitest unit tests
src/routes/domegallery/+page.svelte           # demo page
src/lib/types.ts                              # DomeGalleryProps + DomeGalleryImage + DomeGalleryItem
